Vertical Shaft Impact Crusher

Capacity

60-640TPH

Speed

900-1930（r/min）

Applications: Aggregates Shaping, Mechanism sand, Bituminous Concrete, Metal Mine, Chemical, Road, Railway,Metallurgy, Construction, Highway, Water Conservancy

Equipment Type: High-Efficiency VSI Vertical Shaft Impact Crusher / VSI Sand Maker

Core Function: Advanced Impact Sand Making Machine for Quartz, River Stone, and Granite

Social Media

What is Vertical Shaft Impact Crusher?

As a premier VSI crusher manufacturer, we engineered the VSI vertical shaft impact crusher to meet the highest standards of modern aggregate production. This heavy-duty vertical shaft impact crusher adopts advanced "rock-on-rock" and "rock-on-iron" crushing principles, making it an indispensable impact sand making machine for quarry operators worldwide. Whether you are looking for a reliable vsi rock crusher to process hard granite, or establishing a complete vsi crusher plant for large-scale production, our equipment delivers unparalleled cubical particle shaping and maximum throughput.
Our sand manufacturing machine is highly versatile and specifically optimized for producing high-quality concrete aggregates. It serves as a core m sand crusher in the following fields:
M-Sand Production: Ideal m sand crusher machine for turning river pebbles, limestone, and basalt into premium manufactured sand (M-Sand).
Mining & Quarrying: Functions perfectly as an impact sand making machine inside any VSI crusher plant to reduce fines and improve shape.
Industrial Minerals: Processing abrasive materials like quartz, silica, and clinker with minimal wear and tear.

What is the working principle of the Vertical Shaft Impact Crusher?

Our vsi vertical shaft impact crusher utilizes high-velocity kinetic energy, rather than mechanical pressure, to crush and shape materials through a highly efficient 3-step process:

Precise Feeding & Splitting

Raw material enters the top hopper of the sand manufacturing machine, where a specialized bulk tray splits it into two streams. One stream drops directly into the center rotor, while the other cascades around the exterior to form a continuous "material curtain" inside the vsi crusher plant.

High-Speed Centrifugal Acceleration

The material inside the center rotor is spun rapidly by extreme centrifugal force. Accelerated to high speeds, the stones gain intense kinetic energy before being launched outward through the discharge ports of this advanced vsi sand maker.

High-Intensity Impact Crushing

As the stones fly out, they collide violently with either a natural rock lining (Rock-on-Rock mode for premium shaping) or heavy-duty alloy anvils (Rock-on-Iron mode for high-capacity m sand crusher lines). This intense self-friction and impact eliminate stress cracks, discharging perfectly cubical aggregate ideal for any vsi crusher sand project.

VSI crusher working principle diagram showing rock-on-rock crushing action

Model	Capacity (T/H)	The max feeding size(mm)	Speed（r/min）	Double motor power（kW）	Dimension L×W×H (MM)	Weight (t)	Lubrication station
VSI7611	120-180	60-90	≤35	≤30	1700-1930	2X55	4100x2250x2315	8	2X0.55	One dual oil pump works one by one, and the standby oil pump is automatically turned on when the flow is low. High oil temperature, automatic shutdown without oil return,Air cooler lowers oil temperature, heater warms up oil temperature in winter.	1200X790X1120	2
VSI8518	200-260	100-130	≤40	≤35	1520-1690	2X90	4160x2300x2476	12
VSI9526	300-380	150-190	≤45	≤40	1360-1510	2X132	4540x2500x2911	13
VSI1140	450-520	225-260	≤50	≤45	1180-1300	2X200	5000x2716x3117	18.5
VSI1145	500-640	250-360	≤50	≤45	1200-1390	2X220	5450x2900x3300	19.5
VSI1150	413-663	344-368	≤50	≤45	1200-1390	2X250	5450×2900×3365	19.8
VSI1263	545-583	454-486	≤60	≤50	900-1150	2X315	5700x2980x3530	19

Model

Capacity (T/H)

The max feeding size(mm)

Speed（r/min）

Double motor power（kW）

Dimension L×W×H (MM)

Weight (t)

Lubrication station

Double oil pump motor power（kW）

Security

OverDimension L×W×H(mm

Tank heater power（kW）(kW)

Surrounding feed and center feed

Full center feed

Soft stone

Hard Material

VSI7611

120-180

60-90

≤35

≤30

1700-1930

2X55

4100x2250x2315

2X0.55

One dual oil pump works one by one, and the standby oil pump is automatically turned on when the flow is low. High oil temperature, automatic shutdown without oil return,Air cooler lowers oil temperature, heater warms up oil temperature in winter.

1200X790X1120

VSI8518

200-260

100-130

≤40

≤35

1520-1690

2X90

4160x2300x2476

VSI9526

300-380

150-190

≤45

≤40

1360-1510

2X132

4540x2500x2911

VSI1140

450-520

225-260

≤50

≤45

1180-1300

2X200

5000x2716x3117

18.5

VSI1145

500-640

250-360

≤50

≤45

1200-1390

2X220

5450x2900x3300

19.5

VSI1150

413-663

344-368

≤50

≤45

1200-1390

2X250

5450×2900×3365

19.8

VSI1263

545-583

454-486

≤60

≤50

900-1150

2X315

5700x2980x3530

Common Problems

This section is designed to address the most pressing inquiries customers may have regarding the daily operation, maintenance, product advantages, and after-sales service of our machine. Our aim is to help you gain a comprehensive understanding of our overall capabilities and enable you to make informed decisions for your projects.

While cone crushers excel at secondary or tertiary reduction, a vertical shaft impact crusher for sale is specifically designed for fine crushing and shaping. It utilizes high-speed impact to crush rocks, functioning as the ultimate impact sand making machine to produce stress-free, cubical sand that increases concrete strength.

The total vsi crusher price depends on the specific model capacity, motor configuration, and whether you require optional hydraulic components. As a direct vsi crusher manufacturer, we configure setups according to your budget to ensure you get the most economical sand crusher price without middlemen markups.

Yes. By adjusting the rotor speed and the feeding ratio of the sand manufacturing machine, you can easily control the gradation and fineness modulus of the output. This flexibility makes it the ideal m sand crusher for various asphalt and concrete mixing requirements.

"M-sand" stands for manufactured sand. An m sand crusher machine is engineered with heavy-duty internal protection to handle exceptionally hard rocks like basalt and granite. If you are setting up an commercial aggregate line, our m sand crusher configuration ensures higher durability and better throughput.

The wear life depends entirely on the abrasiveness of the material you feed into the vsi rock crusher. For soft limestone, wear parts last significantly longer than for hard river pebbles. We use top-tier alloys to ensure our vsi crusher machine outlasts standard market alternatives.

Absolutely. As an experienced vsi crusher manufacturer, we don't just sell single machines. We design, supply, and commission full-scale vsi crusher plant projects, including feeders, screens, conveyors, and the core vsi vertical shaft impact crusher units.

You can click our inquiry button to leave your raw material type, required capacity (TPH), and contact info. Our engineering team will immediately calculate a tailored technical proposal and provide a competitive m sand crusher machine price quote within 24 hours.

Yes. Our vsi sand maker features an upgraded non-clogging discharge cavity. When configured for a vsi crusher sand production line, it can process wet or semi-wet raw materials efficiently without blockages, making it perfect for river stone processing.

COMPREHENSIVE SERVICE & GENUINE SPARE PARTS

Zhongxin Heavy Industry provides not only high-performance equipment but also full life-cycle support solutions.

Genuine VSI Crusher Wear Parts

Original rotor tips, feed tubes, anvils, and upper/lower wear plates ensure perfect fit and maximum wear life for your vertical shaft impact crusher. Genuine parts reduce downtime and maintain sand making efficiency

Professional Technical Support

Our team provides installation guidance, operation training, and troubleshooting to keep your VSI crusher running at peak performance. We offer 24/7 online support and can send engineers overseas for on-site assistance

Fast Parts Delivery

Global parts network ensures rapid supply of genuine components for all VSI models, including rotor assemblies and wear parts. Spare parts are available at cost price with lifelong supply commitment
